ClimateMaster TMW036 - TMW036 - 120 - Unit Dimensional Data

THE SMART SOLUTION FOR ENERGY EFFICIENCY
Tranquility
®
Water-to-Water (TMW) Series
Rev.: 04/15/16
7
climatemaster.com
TMW036 - 120 - Unit Dimensional Data
B
C
A
M
L
K
1.0
(2.5 cm)
1
2
3
4
5
6
J
H
G
F
E
D
Required
Service Access
Optional
Service Access
1.8
(4.6 cm)
1.0
(2.5 cm)
3 Ft
3 Ft
Notes 1 & 2
Notes 1 & 2
1
2
3
4
5
6
Required
Service Access
Optional
Service Access
B
C
A
1.3
(3.3 cm)
2.7
(6.9 cm)
(18.3 cm)
(4.3 cm)
7.2
1.7
3 Ft
Notes 1 & 2
3 Ft
Notes 1 & 2
(7.4 cm
)
2.9
(10.1 c
m
4.0
Water to
Water
Overall Cabinet
Water Connections
Electric Access Plugs
123 4 56
A
Depth
B
Width
C
Height
D
Source
(Outdoor)
Water In
E
Source
(Outdoor)
Water
Out
F
Load
(Indoor)
Water In
G
Load
(Indoor)
Water Out
H
HWG
Water In
J
HWG
Water
Out
K
Low
Voltage
L
External
Pump
M
Power
Supply
036-060
in. 30.6 25.4 33 2.7 9.4 19.4 24.5 27.9 30.4 20.9 22.9 30.9
cm. 77.8 64.5 83.8 6.9 23.9 49.3 62.2 70.9 77.2 53.1 58.2 78.5
120
in. 30.6 52.9 37 25.2 25.2 30.1 30.1 34.9 34.9 29.9 31.9 34.4
cm. 77.8 134.4 94 64.0 64.0 76.5 76.5 88.6 88.6 75.9 81.0 87.4
Notes:
1. Front & side access is preferred for service access. However, all
components may be serviced from the front access panel if side
access is not available.
2. While clear access to all removable panels is not required,
installer should take care to comply with all building codes and
allow adequate clearance for future field services.
