CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Water-to-Water (TMW) Series
Rev.: 04/15/16
6
ClimateMaster Water-Source Heat Pumps
Unit Physical Data
Model 036 060 120 170 340
Compressor (qty) Scroll (1) Scroll (2) Scroll (1) Scroll (2)
Factory Charge HFC-410A (lbs) [kg] per
circuit
4.5 [2.04] 5.5 [2.49] 14.9 [6.8]
Water Connection Size
Source/Load (in) 3/4 1 1-1/2 2
Hot Water Generator FPT (in)
½
N/A
Weight - Operating (lbs) [kg] 348 [158] 360 [163] 726 [329] 725 [329] 1330 [604]
Weight - Packaged (lbs) [kg] 373 [169] 385 [175] 770 [349] 765 [347] 1340 [608]
Water Volume (Source)
Gallons (Liters) 0.96 (3.64) 1.33 (5.04) 2.65 (10.02) 3.50 (13.27) 6.72 (25.44)
Dual isolated compressor mounting
Balanced port expansion valve (TXV)
Insulated Source and Load Water Coils standard
Insulated Refrigerant Circuit standard
Compressor on (green) and fault (red) light
Unit Maximum Water Working Pressure
Options Max Working Pressure PSIG [kPa]
Base Unit 300 [2,068]
