Areas commands
For each areas you can set the commands listed in the table below. There are 7 records for each areas:
first record : area 1 => 10, area 2 => 17, area 3 => 24,…, area 12 => 87
Note: If mode area = 0, The area will follow the local programming set to EC2 (Or any area mode manual forcing)
Address Description Notes Limits
10 Winter comfort Setpoint area 1 8.0°C…35.0°C
11 Summer comfort setpoint area 1 8.0°C…35.0°C
12 Delta winter setpoint eco area 1 Positive value. In Eco mode will be subtracted from the comfort Setpoint 0.1°C…15.0°C
13 Delta summer setpoint eco area 1 Positive value. In Eco mode will be added to the comfort Setpoint 0.1°C…15.0°C
14 Area 1mode 1 = area off, 2 = area Eco, 3 = area comfort
15 Winter humidity Setpoint area 1 10%...90%
16 Summer humidity Setpoint area 1 10%...90%
Domestic Hot Water commands
Address Description Notes Limits
110 Setpoint reload DHW 25°C…55°C
111 Setpoint maintenance DHW 25°C…55°C
112 DHW profile
1 = Maintenance + recirculation, 2 = Maintenance,
3 = recirculation+ recharge, 4 = recharge
ElfoFresh commands
For each ElfoFresh (EF) areas you can set the commands listed in the table below. There are 5 records for each ElfoFresh:
first record : EF 1 => 115, EF 2 => 120, EF 3 => 125, EF 4 => 130
Address Description Notes Limits
115 Winter Setpoint room temperature 18.0°C…26.0°C
116 Summer Setpoint room temperature 22.0°C…28.0°C
117 Winter room humidity Setpoint 5%…80%
118 Summer room humidity Setpoint 45%…100%
119 Functionnning mode 1 = EF disabled, 2 = EF fan mode only, 3 = auto mode
Status record (read only)
Plant stata
Address Description Notes
140 Plant status 1 = off, 2 = on
141 Plant mode 1 = cooling, 2 = heating
142 Heat pump status 0 = off(or standby), 1 = plant, 2 = DHW
143 Outdoor temperature
144 heat pump alarm 0 = not alarm, 1 = alarm
145 Heat pump supply temperature
146 Compressor heat pump power 0…100% (in decimi di %)
147
heat pump working Setpoint
