CLIVET ELFOControl2 User Manual

Page 55
SYSTEM COMPONENT ADDRESSING
MIXING MODULE
RS485
NLNNNNL1 L 2 L 3 L4
-
SL
6
7
8
9
g
nd
10
11
1
2
gnd
BT
1
V3
V2
V1
N
AP1
RS485
X1
1
2
PE
FUSE 6.3 A type T
RS
485
-
+
GND
Follow the instruction at page 51 or 52
Parameters to be modified
Parameter
Mnemonic
Name
Description Value
33 Index Device address 50..,52
34 Baud Rate
Baud Rate 0=4800 1 :9600
2 :19200
1
35 Parity
Parity 0=NO / 1=Odd 2=Even
supervision serial
0
HID-T2 Temperature
HID-T3 Temp. + humidity
HID-TI2 Temperature
uncased
*
*
For module RS485 see below.
RS485 MODULE
The addressing can be performed:
• from thermostat
• via selectors on RS485 module
From thermostat:
1 - set selector switches
S5 = ON = 100 (hundreds)
S4 = 9 (unit)
S3 = 8 (tens)
2 - set parameters 33,34,35
From selector switches
1 - set the address using selector switches
S4 = unit
S3 = tens
example : 17 = S4 =1 , S3 =7
2 - set using thermostat par.. 34 and 35.
BT2 EXSTERNAL TEMPERATURE READING PROBE
PE3S0006 - Option
Enable BT2 probe:
• System setting menu (page 26)
• Parameter menu
• Setting par.1 = mixing module
3
J
3S
4S
ON
ON
S1
S2
ON
RS485
LR
LV
J1
G
N
D
-
+
5S
