Menu level
1
2 cycles
4 cycles
Super 4 cycles
Spot welding
External
1
5
43
2
Select requested parameter and adjust by handwheel
Voltage ACTUAL value
Converted power
Wire feed
Sheet thickness preview
Current ACTUAL value
Current preview
Arc fine adjustment
Voltage preview
CAUTION: In synergy mode all other parameters will be auto-
matically adapted in the background.
Functions in the menu level:
• Turn handwheel: select
• Press handwheel: activate
Wire feed as
reference vari-
able
LED description
LED : Ready for operation
LED : Welding
LED : Failure
Press the
handwheel:
Open the job quick
memory menu
Save current setting:
- Select job No. (S1-S5)
- Press handwheel for 2 seconds
Delete welding job:
- Select job to be deleted
- Press handwheel for 4 seconds
Press
the handwheel
LED off:
Fine adjustment -
arc length
LED on:
Fine adjustment -
arc dynamics
Measured value display
5
Arc fine
adjustment
4
Adjust welding capacity
3
Select operating
mode
2
Brief instruction Basic settings for commissioning
