MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 24 of 127
It is absolutely forbidden to direct high-
pressure jets of water onto the support
containing the battery pack.
High water pressure could generate seri-
ous and irreversible problems in the oper-
ation of the machine.
3.2 Platform control stations
There are two platform control stations:
1. the main one (operating) is the AUTEC control
station (*optional) fixed and cabled in the basket
(Picture 12);
2. the second one (emergency) is the AUTEC ra-
dio control station (Picture 8);
3. the third one (emergency) is totally hydraulic
with electrovalves located on the frame (Picture
15).
It is not possible to use two different con-
trol station at the same time.
The system will select as actual control station the
first one that will be used by the operator. Once the
AUTEC remote control station is connected, it will be-
come the actual control station, and in order to select
a different control station you need to turn off and
back on the system by the ignition key or any of the
emergency buttons on the machine (except the one
on AUTEC remote control).
3.2.1 Platform (operating) control sta-
tion
The main platform (operating) control station consists
of the AUTEC radio control (Picture 8).
It can be activated only by carrying out the connec-
tion procedure described below (radio control activa-
tion directly excludes the basket control station).
Radio control link procedure:
1. To connect the radio control, press the green
Start/Link button SL (Picture 7) down on the left
side.
2. the green led light “Power” on the upper right
side of the electronic panel (Picture 9) of the ra-
dio control comes on.
