MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 27 of 127
The radio control has the following commands (Pic-
ture 8):
- on the left side:
• a green start/link key;
• a blue coding key CK (Picture 14), which
puts the console in communication with
the machine control unit. Be careful not to
lose it!
• parking button P: it has multiple func-
tions; one of the most important is the au-
tomatic return of the booms in the rest po-
sition.
- on the central electronic panel:
• joystick J1 for travel of left track (or-
ange) / basket levelling (white) / basket
rotation (yellow);
• joystick J2 for telescopic boom extrac-
tion/return (yellow);
• joystick J3 for boom lifting/lowering
(yellow);
• joystick J4 for lifting/lowering and ex-
traction/return of pantograph (yellow);
• joystick J5 for narrowing/widening of
tracks (orange) (*optional) / turret rota-
tion (yellow);
• joystick J6 for travel of right track (or-
ange) / jib lifting/lowering;
• emergency red mushroom-shaped but-
ton EB that blocks the machine, removing
the power supply to the control circuits.
This button has priority over all other com-
mands; thus, it allows only manual de-
scent to the ground. The emergency but-
ton has a mechanical locking device;
therefore, it must be unlocked by turning it
clockwise to reactivate the normal ma-
chine working.
• lever 7 for travel block bypass: it allows
to bypass the travel block in case of maxi-
mum slope reaching, keeping the lever up-
ward;
• lever 8 for endothermic or electric* en-
gine power on/off;
