MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 29 of 127
7. EARLY WARNING LIGHT - MOMENT
LIMITER (*optional)
8. LED – 85-100% BATTERY CHARGE
(*optional)
9.
10. LED – FRAME LEVELLED
11.
12. LED – BASKET CENTRED
13.
14.
15. WARNING LIGHT – MOMENT LIMITER
BLOCK (*optional)
16. LED – 60-85% BATTERY CHARGE
(*optional)
17. LEFT REAR STABILIZER TO THE
GROUND
18.
19. RIGHT REAR STABILIZER TO THE
GROUND
20. LED – BASKET LEVELLED
21.
22.
23. LED – BASKET OVERLOAD (*op-
tional – only with load cell)
24. LED – 35-60% BATTERY CHARGE
(*optional)
25. LED – BOOMS CLOSED
26. LED – TURRET CENTRED
27. LED – BOOMS WITHDRAWN
28.
29. LED – AERIAL PART USE CONSENT
30. LED – MACHINE STABILIZED
31. LED – MACHINE READY TO TRAVEL
32. LED – 10-35% BATTERY CHARGE
(*optional).
If all leds of battery* charge flash, a battery
malfunction or a connection missed (CAN-
bus) is signalled.
If only the bottom led (10%) flashes, the
battery pack (*optional) charge is too low
(under minimum threshold) and the ma-
chine is near to go in block.
3.2.1.1 Recharge of radio control bat-
teries
The remote control is equipped with two interchangeable
batteries (one mounted and one spare).
It is advisable to always keep the unused battery charged
and, in any case, to ensure that it is being charged during
non-working hours.
