MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 38 of 127
Comply with the rules in force about width,
height, weight and transport speed allowed.
Check that the limit gauge is compatible with
the features of the route to be made (i.e. gal-
leries, bridges, electrical and phone lines,
etc.).
WARNING! In both cases, it is advisable to
remove the basket to favor the operations
and reduce encumbrances.
Always use the radio control for load-
ing/unloading operations.
4.3.1 Loading/unloading through ramp
Check that no one is in proximity and that
the MEWP is in transport configuration.
The tracks should be extended to maximum
width for improved stability and increased
ground clearance when loading and unload-
ing the MEWP using ramps (*optional), mov-
ing to the right the joystick J5 on the radio
control (Picture 8b).
Place the couple of adequate ramps in corre-
spondence of the machine tracks.
Check that the ramps slope does not ex-
ceed 17° (31%) and that those are perfectly
clean from grease, mud, snow or ice.
WARNING! If you get the machine on a
truck, use loading ramps with suitable di-
mensions and strength. Secure the ma-
chine to the truck plane by couplings on
the chassis. Ensure that the machine is
switched off during the transport.
1. Switch on the MEWP engine.
2. connect and use the radio control.
Check that the slope approach angle is
not higher than 14° (25%) and that they are
perfectly clean from grease, mud, snow or ice.
