MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 39 of 127
3. Control the travel maneuvers slowly and ex-
clusively by radio control. Travel and climb
with the MEWP set as shown below: the
basket shall always be placed at the rear of
the machine.
In order to favor machine loading/unloading through
ramp, with the MEWP in transport position, even if it
is not stabilized, you can press the parking button P
(Picture 8) to:
o lift/lower the jib;
o rotate and level the basket;
o return the booms on their support.
In order to avoid the overturning of the
MEWP, use the roll-over control lever 9 (Pic-
ture 8), present on radio control station: it
moves front or rear outriggers closer to the
ground.
4.3.2 Travel
The machine, thanks to a variable flow engine, has
three levels of speed identified by three different sym-
bols:
o "turtle": minimum speed;
o "hare": average speed (*optional);
o "double hare": maximum speed (*optional).
Check that no one is in proximity and that
the MEWP is in transport configuration.
The tracks should remain extended to maxi-
mum width for improved stability and in-
creased ground clearance when traveling with
the MEWP (*optional). The exception is when
traveling through a narrow passage, the
tracks may need to be retracted to decrease
the overall width of the MEWP. It is recom-
mended that the tracks be extended again as
soon as possible.
