MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 40 of 127
Check that the travel slope does not ex-
ceed the maximum longitudinal limit of 17°
(31%) and the maximum transversal limit
of 10° (18%). Check that the soil is clean from
grease, mud, snow or ice.
WARNING! The hydraulic system through
which the maximum speed (“double hare”)
is activated is a serial system (*optional).
Therefore, it may be necessary to inter-
vene with manual corrections during han-
dling. Be very careful to travel with maxi-
mum speed!
Travel operations shall be made with the basket
placed at the rear of the machine.
During travel, if necessary, the parking
button P allows to lift jib in order to avoid
obstacles or its contact with the ground;
moreover, it is possible lower two front stabi-
lizers or two rear stabilizers until to brush up
against the soil, using the lever 9 (Picture 8)
to balance the weight of machine.
Always use the radio control from the
ground for travel operations.
C.M.C. forbids you to move it from the bas-
ket, because it can entail risks for the
safety of the operator on board.
The travel slope limits are lower from the
basket control station: 11° (pre-alarm at 8°)
longitudinally and 5° (pre-alarm at 2°)
transversally. If the basket operator de-
cides to travel the MEWP from basket con-
trol station, he shall lower completely the
jib.
4.3.2.1 Travel commands on radio control
In order to perform a travel, using the radio control
(Picture 17):
1. make sure all outriggers are raised off the
ground;
2. make sure the basket block pin is inserted;
3. make sure the booms are returned and on
their support;
4. turn on the machine (par. 3.1);
