MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 56 of 127
In case of moment limiter device (*op-
tional) supplied, for all aerial movements
described above, it will be necessary to
unseal and keep pressed, in the meantime,
the red cursor of the solenoid valve R lo-
cated in the turret (Picture 23b).
If necessary, the basket operator can oper-
ate:
• the basket centering, pressing the valve
cursor placed on jib (Picture 24), with a
pointed object;
• the basket rotation, pressing the valve
cursor placed on jib (Picture 24) and an-
other ground operator keep pressed the
cursor 5 on emergency workbench (Pic-
ture 23a).
Picture 24: valve cursor for basket centering.
While return the MEWP in rest configura-
tion, the deceleration ramps of the maneu-
ver speeds will be inactive: therefore, pay
particular attention to the operations wear-
ing all personal protection equipment pro-
vided by law.
At the end of aerial part recovery, it is pos-
sible to get the operators off the basket.
