MAN.241 Rev.5 ENG - Use and maintenance manual S23 page 97 of 127
Voltage Input
100 - 240
Vac
Frequency Input
50 - 60
Hz
Maximum Output Voltage
>=60
V
Maximum Current
22
A
PWM Frequency
1
kHz
International Protection
IP20
Weight
2,2
Kg
Dimension (L*W*H)
180x310x100
mm
8.13 Consumables 
Hydraulic oil:
(hydraulic tank capacity: 25 l)
Gazpromneft Hydraulic HDZ 32 o 46
32
46
Density, 15°C, kg/l
ASTM
D4052
0,867
0,874
Kinematic Viscos-
ity, 40°C, mm2/s
ASTM D445
32
46
Kinematic Viscos-
ity, 100°C, mm2/s
ASTM D445
6,45
8,16
Viscosity Index
ASTM
D2270
151
154
Pour point °C
ASTM D97
-42
-42
Flash point COC,
°C
ASTM D92
216
228
A biodegradable hydraulic oil, called BIOHYDRAN
TMP 46, can be supplied as *optional:
Density, 15°C, kg/l
ASTM D4052
0,920
Kinematic Viscosity, 40°C,
mm2/s
ASTM D445
46
Kinematic Viscosity, 100°C,
mm2/s
ASTM D445
9,3
Viscosity Index
ASTM D2270
185
Pour point °C
ASTM D97
-42
Flash point COC, °C
ASTM D92
300
In case of refilling or replacement, it is im-
perative to use the same hydraulic oil (or
equivalent) and respect the technical
specifications of the product already pre-
sent in the hydraulic circuit.
Motor oil:
Texaco Motor Oil S 5W-40
Density, 15°C, kg/l
ASTM D4052
0,850
Kinematic Viscosity, 40°C,
mm2/s
ASTM D445
76
Kinematic Viscosity, 100°C,
mm2/s
ASTM D445
12,9
Viscosity Index
ASTM D2270
171
Pour point °C
ASTM D97
-43
