Motor Tuning and Setup for X, Y, Z, A, B and C axis, the user needs to set suitable
values.
Figure 44, Mach3 Spindle tuning
Figure 45, Mach3 Spindle Max speed. 0-10v
Spindle Tuning and Spindle speed need to be set to get analog output 0-10V for entire spindle
speed range. The value 10000 rpm is recommended during adjust analog output. But Actual
speed will be used instead after finishing setup.
www.CNCRoom.com Page 33
