COBHAM Explorer 510 - Battery Specifications; Interface Specifications

Appendix A: Technical specifications
98-143082-D Battery specifications (internal battery) 96
Battery specifications (internal battery)
Interfaces specifications
Power input
Item Specification
Battery type Lithium Ion, rechargeable
Time between recharging
Stand-by
Tx time, max
Rx time, max
24 h (0 to 55C/ 32 to 131F)
2 h 25 m @ 128 kbps (25°C / 77F)
4 h 40 m @ 128 kbps (25°C / 77F)
Charge time without precharging
Charge time including precharging
(battery completely discharged)
Less than 4 hours
12 to 24 hours
Charge temperature 0 to 45C,/ 32 to113F (Japan: 10 to 45C/ 50 - 113F)
Min. charge cycles 300 (typically up to 500)
Item Specification
DC input range 10.5 to 32 VDC
Power consumption
Standby / transmit
During charging
2.8 W / 19 W (typical)
38 W (max.)
Connector type 2.5 mm EIAJ RC-5320-IV
