Appendix A: Technical specifications
98-143082-D Interfaces specifications 97
WLAN access point
USB (Host) interface
Connector pin-out
Specifications
Item Specification
Standard IEEE 802.11 b/g
Antenna Built-in
Frequencies 2.4 GHz ISM band
Pin Function
1VBUS
2D-
3D+
4GND
Item Specification
Version USB v2.0 Host
Connector type
Type A
Charge current available 0.5 A or 1.0 A, user selectable
Max. cable length 5 m / 16.4 ft
