Appendix A: Technical specifications
98-143082-D Built-in BGAN antenna 98
Built-in BGAN antenna
AC/DC adapter
Item Specification
Type Directional patch array, manually adjustable
Polarization RHCP, Right-hand circular polarization for both tx and rx
Frequencies
Inmarsat I-4
Transmit
Receive
Inmarsat Alphasat (EMEA)
Transmit
Receive
GNSS
1626,5 MHz - 1660,5 MHz
1525 MHz - 1559 MHz
Extended L-band (XL)
a
:
1626,5 MHz - 1660,5 MHz and 1668 MHz - 1675 MHz
1518 MHz - 1559 MHz
GPS, GLONASS, Beidou
a. Only available within Alphasat coverage (EMEA). See Satellite coverage on page 100.
EIRP Nominal: 15.1 dBW ±1dB, Class 2
Gain 11 dBi
Item Specification
AC input range 100 to 240 VAC, 47 to 63 Hz, 50 W
DC output 19 VDC
