The web interface
98-145510-E Chapter 6: Setup and operation 6-19
To set up reporting SNMP traps to an SNMP server, do as follows:
1. Select SETTINGS > Reporting.
2. In the section SNMP traps select On to enable sending of SNMP traps (default: Off).
3. Enter the IP address of the SNMP trap receiver/manager to which the SNMP traps will be
sent.
4. Enter the Community name. This is the name of the SNMP trap receiver/manager. This is
needed for authentication of the SNMP trap request.
5. Click Apply.
6.1.12 Stow input (discrete I/O)
You can use pin 5 on the I/O connector on the ACU to force the antenna to stow. E.g. if you
connect pin 5 to the ignition and enable the stow input in the web interface, the antenna
will automatically stow when you start the vehicle. Do as follows:
1. Connect pin 1 in the I/O connector to GND in your connected equipment, e.g. the
ignition system of your vehicle.
2. Connect pin 5 in the User I/O connector to “high” when the antenna should be forced to
stow, e.g. when the ignition in the vehicle is switched on.
For specifications for the User I/O interface, see Interfaces of the antenna on page 4-8.
3. Connect pin 5 in the User I/O connector to GND when the normal stow functions should
apply, e.g. when the ignition is off.
4. In the web interface, select SETTINGS > Discrete I/O.
5. Under Stow input, select Enable.
6. Click Apply.
The antenna will now automatically stow when voltage is applied to pin 5 in the User I/O
connector. When pin 5 is connected to GND, the normal stow functions apply.
6.1.13 Compass calibration
With the system installed in the vehicle, park the vehicle and make a compass calibration in
4 directions with approximately 90 degrees between them.
Do as follows:
1. Make sure the antenna is stowed before calibration.
You must make a compass calibration after first installation and every time
the antenna is reinstalled. If the compass is not calibrated the system will
not work properly!
You can set up whether or not you need administrator password to access
calibration. See User permissions (guest login) on page 6-24.
