Product Overview
1.1 DVR Front and Side Panel
1.2 DVR Rear Panel
1. PWR – Power LED lights when powered on
2. VGA – Output using a VGA cable
3. Video/Audio Input/Output
1. HDMI Port
2. LAN – Ethernet connection to modem / router (required for remote viewing over internet or
mobile)
3. USB Ports x2 – For mouse and ash drive backup / rmware updates
4. RS485 – For use with PTZ cameras (Cable and PTZ camera not included)
5. 5V Socket – Connect 5V Power Adaptor
1
1
2
2
3
3
4
5
