Manpack Transceiver 2110 series Getting Started Guide 31
CODAN
4 The front panel
Overview
The front panel has three main areas: user controls, connectors
and antennas, as shown in Figure 3.
Figure 3: The front panel (2110 model shown)
NOTE
The 2110v Manpack Transceiver uses a 5-way
connector in place of the 19-way GPIO
connector ( ) on the 2110 Manpack
Transceiver.
interface
connectorsuser controlsantennas
infrared
window
internal
GPS
antenna
(if fitted)
internal
speaker
earth
terminal
