Manpack Transceiver 2110 series Getting Started Guide 67
CODAN
Appendix D—Transceiver
specifications
Table 8: 2110 series Manpack Transceiver
specifications
Item Specification
Frequency range Transmit: 1.6 to 30 MHz
Receive: 250 kHz to 30 MHz
Channel capacity 400 channels
600 channels with MIL-STD-188-141B ALE option
(2110 only)
Operating modes Single sideband (J3E) USB and LSB or switched USB/LSB,
AM H3E (optional)
Sensitivity Frequency:
0.25 to 30 MHz
RF amp off:
0.28 µV PD, –118 dBm
Frequency:
1.6 to 30 MHz
RF amp on:
0.14 µV PD, –124 dBm
For 10 dB SINAD with greater than 50 mW audio output
Power output 25 W PEP ±0.5 dB (high power)
5 W PEP ±0.5 dB (low power)
Antenna tuning
times
First time tuning: 2.5 s typical
Memory tuning: 50 ms typical
Approximate
battery life
(based on Tx:Rx
ratio of 1:9)
13 Ah NiMH: 50 hours
8Ah NiMH: 30hours
7 Ah SLA: 15 hours
To Next Page
