The front panel
Manpack Transceiver 2110 series Getting Started Guide 33
Hold to go from any location to the home screen. If you
have entered text into a setting and want to discard the
changes you made, hold .
The scroll keys
The and keys are the scroll keys. Use these keys to scroll
up or down through any list, to scroll left or right over text,
and to increase or decrease a value.
Interface connectors
The interface connector area comprises:
• the 6-way handset connector ( )
• the 19-way GPIO connector ( ) (2110 only)
• the 5-way connector ( ) (2110v only)
Antennas
The antenna area comprises:
• the antenna stud ( ) for whip antennas and the adaptor
for the long wire antenna
• the 50 Ω connector ( ) for broadband and dipole
antennas
