The front panel
Manpack Transceiver 2110 series Getting Started Guide 35
V/S Pressing V/S toggles the mute type between Voice mute and
Selcall mute.
SEC Pressing or holding SEC enters Secure mode, if the hardware
option is fitted, and special firmware is programmed into the
transceiver and enabled.
GPS Pressing GPS displays your current GPS position, if the
hardware option is fitted and enabled.
EASITALK Pressing EASITALK toggles the DSP noise reduction algorithm
on or off.
VIEW Pressing VIEW toggles between the channel screen and the
Address List.
CALL LOGS Pressing CALL LOGS repeatedly steps through a number of
call logs: Calls Out, Calls In, Last Heard, then back to the screen
from which you began. In these logs, you can view the details of
the calls or detected stations.
The Last Heard log is only available if you have the MIL-STD-
188-141B ALE option installed (2110 only).
(Emergency) Holding begins an automatic Emergency call transmission
using call information contained in the Emergency entries in the
Address List.
(Power) Pressing toggles the screen and keypad backlighting between
the default setting and off.
+ 9 Pressing + 9 enables you to change the default setting for the
screen contrast.
+ 0 Pressing + 0 enables you to change the default setting for the
screen and keypad backlighting.
Table 6: Standard hot keys (cont.)
Hot key Function
