3. Manual Control of Fixtures
We will introduce how to manually control fixtures in this chapter.
3.1. Select Manual Control of Fixtures
First of all, select the units need to be controlled. Select the page in Unit section, then select the units buttons
need to be controlled.
Shortcut: If you need to select Unit button 1-10, you only need to press Unit button 1 and hold still until you
press Unit button 10.
Note: If the Unit buttons had not patched to any fixtures, you can not choose Units and the led of the Unit buttons
will not on.
3.2. Manual Control of Fixtures
It's very easy to control fixtures manually. Operate steps: Select the fixture and open the white light beam first,
then adjust the attributes of the fixtures or run the internal Effects of the console.
3.2.1. Turn on the light beam
Select the fixtures, one or more at one time.
Operate steps:
Select the fixtures in Unit section;
Press Locate;
Press S1 [Locate Fix.] to turn on light beam, median value automatically set into Pan/Tilt.
3.2.2. Look Over the Output Value
Under the manual Mode, the LCD screen displays the present attributes value.
Show as: Channel No. + CH + output value, for example: 19CH255, means the output value of No. 19
channel is 255.
Operate Steps:
Press Locate;
Switch to display channels by S2 .
3.2.3. Change the Attribute Values of Fixtures
You can select the attribute button to adjust the relevant attribute you needed, then there will be a particular
noted display on the bottom of the LCD screen, adjust the value by the relevant wheel. Different fixtures
have different attribute value, all of them can be displayed on the LCD screen.
There 10 attribute buttons in attribute section, switch 1-10 to 11-20 by 11-20 button. Each attribute button
