CR2 User’s Manual Draft_022803_AS - 12
CR2 User’s Manual Draft_022803_AS - 13
2.2 - Installation Guide - USB Interface
To connect the CR2 to your host computer via USB interface:
1. Make sure the USB cable is sufciently attached to your CR2 unit (gure 2.1).
2. You DO NOT need to power off your host computer (gure 2.2). The CR2 with
USB interface can be plugged into any host while the computer is powered up.
3. Connect the USB interface cable to the host (gure 2.3). If you are unsure of
the proper location to connect the USB cable please consult the manual of
your host computer.
4. The USB interface does not require additional power supply. If you are using
the 1300 mA or 1800 mA battery for batch mode, the CR2 will automatically recharge
the battery whenever the unit is a attached to a host that is powered up.
5. The CR2 will power on automatically.
6. Scan the following code to set reader into USB communication mode.
Note: You may also scan the code
on page 45 of the User’s Manual
7. Your CR2 unit should
be ready for use.
Open the application
you wish to send data
and begin scanning.
Figure 2.1
Figure 2.2
Figure 2.3
To Next Page
