2.4 - Attaching Handle
Attaching the Handle
To attach the handle, please follow the following steps.
1. Place the CR2 in the cradle of the handle and slide the unit back (gure 2.16).
Be careful not to place ngerprints on the front glass when attaching handle.
2. Once the 8-pin DIN connector of the handle begins to enter the opening in
the back of the unit, rmly press the unit back until the unit is ush against the
handle (gure 2.17).
Figure 2.16
Figure 2.17
