2.5 - CR2 Lithium Ion Battery and CR2 Battery Blank
CR2 Battery Blank
All cabled CR2 units feature a battery blank. THE BATTERY BLANK NEEDS TO BE
ATTACHED AT ALL TIME WHEN USING THE CR2. Installing the battery blank is identical to
installing the battery. Please follow the instructions below.
Attaching and Detaching the Lithium Ion Battery
The CR2 is available with a 1300 mA or 1800 mA Lithium Ion battery. If you wish to purchase,
contact a Code representative. To install battery or battery blank in cradle or to detach battery
from unit, push the locking mechanism up toward the front of the scanner and insert or detach
battery (gures 2.18 & 2.19).
Charging the Lithium Ion Battery
The battery automatically charges everytime a cable inteface is attached to the unit and
the host is powered up
Note: The RS-232 interface power adapter must be plugged into a wall socket for the unit to
charge.
Figure 2.18 Figure 2.19
Battery
Battery Blank
