Technical Manual CODEL
20
5.3.2.1. Press to return to the main display.
From the main display press to reach Diagnostics. Press to access Diagnostic
data.
.
5.3.2.2. Use the key to reach E-C CH1 Diag, and press to access.
5.3.2.3. Use the to reach DRx, and press to access.
5.3.2.4. By following this path, the data displayed on the screen represents the detector level
reading.
5.3.2.5. With the detector levels of E-Cell 1, 2, and 3 established, the final step of commissioning
for the electrochemical cell is the calibration, found in the following section.
1. Meas - 09:24:29
CO: 21 ppm
3. DIAGNOSTICS
3.2. E-C CH1 Diag
