Technical Manual CODEL
21
Electrochemical Cell Calibration
To begin zero calibration of E-Cell, follow the steps below on the display unit.
Note: When ‘Enter to CAL’ 10 has been selected, allow 3 minutes for calibration to complete.
5.3.3.1. Press to return to the main display.
From the main display press to reach Setup Mode. Press to access
Setup options.
.
5.3.3.2. If a Passcode is set, input the passcode in order to access setup options.
5.3.3.3. Use the key to reach Calibration, and press to access.
5.3.3.4. Use the to reach Enter Full EC ZERO CAL, and press to access.
5.3.3.5. FULL EC ZERO CAL: When this menu has been reached, press and the
system will run a zero cal.
1. Meas - 09:24:29
CO: 21 ppm
4. Setup Mode
4.1. CALIBRATION
Full EC Zero CAL
Enter to CAL
