CODEL Tunnel Tech 700 Series User Manual

Technical Manual CODEL
47
7.6. Exit: Allows user to exit to main menu.
 Use or to scroll through to Exit and press to exit to
main menu.
8. Setup Mode: Setup Mode allows users to Setup instruments. An overview of
Setup mode submenus are shown below.
 Setup Mode
 Calibration
 N/A
 Parameters
 Span Factor
 mA Output
 Relay Output
 RTCC
 EEPROM
 PassCode
 Press to exit to main screen, use or to scroll through to
Setup mode.
8.1. CALIBRATION: Allows user to Calibrate. The following are the submenus.
 CALIBRATION
 Enter Full EC Zero Cal
 EC CH1 CAL
 EC CH2 CAL
 EC CH3 CAL
 VIS CH ZERO CAL
 Press to access setup mode sub menus.
8.1.1. Full EC Zero Cal: Allows user to activate EC Full Zero Cal.
 Use or to scroll through to Full EC Zero Cal.
 Press to activate Full EC Zero Cal.
8.1.2. EC CH1 CAL: Allows user to activate Cal of EC CH1
 Use or to scroll through to EC CH1 CAL.
3. DIAGNOSTICS
Exit
3. DIAGNOSTICS
4. Setup Mode
4. Setup Mode
4.1. CALIBRATION
Full EC Zero CAL
Enter to CAL
Full EC Zero CAL
EC CH1 CAL
00000
