Cognex DataMan 362X - Laser Aimers; High Power Illumination Accessories; Cables

Laser Aimers
Laser aimer
DM300-AIMER-00
High Power Illumination Accessories
HPIA, red narrow DM30X-HPIA3-625
HPIA, red wide DM30X-HPIA3-625-W
HPIA, white narrow DM30X-HPIA3-WHI
HPIA, white wide DM30X-HPIA3-WHI-W
HPIA, blue narrow DM30X-HPIA3-470
HPIA, blue wide DM30X-HPIA3-470-W
HPIA, infrared narrow DM30X-HPIA3-IR
HPIA, infrared wide DM30X-HPIA3-IR-W
Note:
l If using the following Cognex high power illumination lights with a DM30X-HPIA-xxx product ID:
l A spacer kit accessory (DMA-SPKIT-30X-00) is required when using the high power illumination
accessory. When the spacer is used, the field of view will be limited for wide-angled lenses.
l A Fair-Rite ferrite (part number 0431167281) must be attached to the External Light cable to reduce
emissions.
Red narrow DM30X-HPIA-625
Red wide DM30X-HPIA-625-W
Red narrow with polarizer DM30X-HPIA-625P
White narrow DM30X-HPIA-WHI
White wide DM30X-HPIA-WHI-W
Blue narrow DM30X-HPIA-470
Blue wide DM30X-HPIA-470-W
Infrared narrow DM30X-HPIA-IR
Infrared wide DM30X-HPIA-IR-W
Cables
Connection cable 24V, I/O, RS-232 (y=S: straight / y=A:
angled *, xx specifies length)
CCB-M12x12Fy-xx
Connection cable 24V, I/O, RS-232 CCBL-05-01
Power and I/O breakout cable, M12-12 (straight, xx
specifies length: 5m, 10m, 15m)
CCB-PWRIO-xx
Power and I/O breakout cable, M12-12 (angled *, xx
specifies length: 5m, 10m, 15m)
CCB-PWRIO-xxR
Connection cable RS-232 CCB-M12xDB9Y-05
