Reading Distance and Field of View (DataMan 360 Readers with a 19 mm
Lens with a Liquid Lens)
The map below shows the FoV of the DataMan 360 series readers with a 19 mm lens with a liquid lens.
The FoV values are shown as follows:
l outer: DM362, DM363
l inner: DM360
The reading distances for the DM360 and DM362 readers are the same. DM363 features a higher resolution and more
pixels in about the same sensor size.
The following table shows the FoV widths in mm at various distances.
Distances in mm DM360
DM362/DM363
50 11 17
100 22 34
150 33 52
250 56 86
500 111 172
36
Setting Up Your DataMan 360
