Cognex DataMan 374 - Installation for Insert Feeder Interface

8
DEC 2021
INSTALL GUIDE
1
INSTALLATION
COGNEX DataMan 374
REV 00
QTL-RND-OPS-00000314-A-00
Figure 1.14 – Vertical mounted reader in maximum left position
QTL-RND-OPS-00000315-A-00
Figure 1.15 – Vertical mounted reader in maximum right position
1.3 INSTALLATION FOR INSERT FEEDER INTERFACE
Installation procedures for a Feeder unit is the same as for a Collate unit. Follow the
same procedures detailed in section 1.2 Installation for Collate & OMR Folder Reading
Interface.
When installing, begin from the Reader back to the board to
ensure any excess cable can be tied back into the reader section.
Figure 1.16 and Figure 1.17 shows the bottom-read reader mounted horizontally and
vertically for a Feeder Reading Interface.
QTL-RND-OPS-00000316-A-00
Figure 1.16 – Bottom-read horizontally mounted reader
