Cognex DataMan 8700 - Page 25

7. Replace the end cap assembly.
8. Insert the screws into the end cap assembly using a Hex 2.0 mm screwdriver.
Note: Use 0.6 Nm (5.31 in-lb) torque on the screws and tighten in the sequence shown in the image.
25
Connection Options
