6.1 User Menu
The User menu function is used for the layout of the Information display menu indication. A
varying content can be assigned to each indication line by the arrow keys. ENTER fixes the content
and it is passed to the next line. With ESC the function is abandoned. The following figure shows an
example of the layout.
The topmost line indicates the program number and the operating condition:
USER MENU >1<
Speed. 50.0 m/Min
Counter 123456
Position 10.0 mm
The following texts can be selected:
Speed xx.xm/Min
Position xxxx.x mm
Mode Normal/Delayed Predisp./Multiple
Preset Value xxxxxx
Counter xxxxxx
Name: xxxxxxx
Predisp. xxxx.x mm
Goods GSC2-3 xxx
6.2 Language
The Language function is used to select the user language by means of the arrow keys. ESC ter-
minates the selection.
USER LANGUAGE
Choice : English
programmer
STOP
User level:
Operating mode:
programmer/operator
STOP
User level:
Operating mode:
5999.530-01E 14.01.2004 CSWM 4 31
