5.3 Label length
The Label length function is used to adjust the length of the label manually or automatically.
LABEL LENGTH
Auto adjust
Manual adjust
5.3.1 Auto adjust
When adjusting the label length automatically, the measuring has to be started by the ENTER key.
The adjustment can be aborted by depressing the ESC key. After starting the adjustment, the paper
web is pulled forward by 2 gaps to measure the label length. If no gap is detected, an error message
appears and the label length is set to 100 mm.
mm gesetzt.
AUTO ADJUST LABEL LENGTH
Auto adjust done
Adjust Label length Length : 100 mm
with [ENTER] Key
User level: programmer
Operating Mode: STOP
Note:
The measured label length should only be considered as an approximate value.
When using this value a fault message may appear, because due to mechanical
slippage the traction roller may cover a distance exceeding the label length.
When the labeller stops are exceeded an error message appears.
Normally after automatic measurement the double or triple label length is ente-
red by hand. The advantage is that the labels not existing on the backing paper
are compensated.
5.3.2 Manual adjust
When adjusting the label length manually, the value is entered by hand. Entering can be aborted by
depressing the ESC key. This function is advantageously used after the auto automatic length mea-
surement. (The label length should be entered twice or three times longer than the actual label length.
Thus labels missed on the backing paper web
LABEL LENGTHSCANNER
Length : 100 mm
User level:
programmer
STOP
Operating mode:
5999.530-01E 14.01.2004 CSWM 4 20
