7.3.9 Test drive
The stepper motor of the traction unit and the motor driver can be tested with the Test Drive functi-
on. For this test the paper web has to be removed. The speed of the stepper motor can be in-
creased or reduced with the arrow keys. The test is terminated with the ESC key.
TEST DRIVE TEST DRIVE
Unload paper Speed
Start with [ENTER] Stop with [ESC]
7.4 Remote Control
The Remote Control function is used to adjust the labeller via the serial interface. This function is
used to set the configuration in the factory. The monitor remains in remote mode until the menu is
abandoned with the ESC key. In remote control mode the labeller is not operating.
REMOTE CONTROL
Serial Port active
9600 Baud 8 Bits
7.5 Working time
The Working time function is used to indicate the total operating time of the monitor.
WORKING TIME
Totaly: 25:16 hrs
7.6 Motor running
The Motor running function is used to indicate the total feed length of the motor. The total length is
indicated in km.
MOTOR RUNNING
Totaly: 12.025 km
programmer
STOP
User level:
Operating mode:
programmer/operator
RUN/STOP
User level:
Operating mode:
programmer/operator
RUN/STOP
User level:
Operating mode:
5999.530-01E 14.01.2004 CSWM 4 41
