InteliATS
NT
STD, SW version 2.0, ©ComAp – June 2010 25
IA-NT- STD-2.0-Reference Guide.pdf
AMF using three-position ATS
G
IA-NT
3x
3xU
M
3xU
G
3x
T
3x
MCB CLOSE/
OPEN
GCB CLOSE/
OPEN
BO
LOAD
ATS
3x
ATS
III0
K4
K3
Specification
• Automatic remote gen-set start when the mains fails (AUT mode)
control, pass through neutral position
fer on mains failure
• Break return on mains return (Load reclosing)
• Test mode (set running and waiting for mains failure)
Hardware requirements
1x IA-NT STD
• Three-position ATS
• Break trans
