InteliATS
NT
STD, SW version 2.0, ©ComAp – June 2010 26
IA-NT- STD-2.0-Reference Guide.pdf
AMF + manual transfer & neutral control using three-position ATS
LOAD
G
IA-NT
3x
3xU
M
3xU
G
3x
T
REM TRANSFER
NEUTRAL POS
3x
MCB CLOSE/
OPEN
GCB CLOSE/
OPEN
BO
BI
3x
ATS
ATS
III0
Force Neutral Position
Manual Load Transfer
K3
K4
K5
NEUTRAL
POS
• -set start when the mains fails (AUT mode)
control, pass through neutral position
est for load transfer (AUT mode)
• Request for switching to neutral position – the highest priority, overrides MCB & GCB state,
forces switch to neutral position. After deactivating return to previous state (MCB or GCB)
Hardware requirements
1x IA-NT STD
Specification
Automatic remote gen
• Three-position ATS
• Manual requ
