InteliATS
NT
STD, SW version 2.0, ©ComAp – June 2010 31
IA-NT- STD-2.0-Reference Guide.pdf
Or by connecting special I-LBA Low Battery Adaptor module:
The I-LBA module ensures min. 350ms voltage dip under following conditions:
Voltage before dip is 12V and after 350ms the voltage recovers to min. allowed voltage 5V.
n.
RS232 and other plug-in module is connected.
The I-LBA enables controller operation from 5VDC (for 10 to 30 sec).
The wiring resistance from battery should be up to 0.1 Ohm for I-LBA proper functio
N :OTE
I-LBA may not eliminate voltage drop when used with low temperature (-40°C) version of controller
and display heating element is on (below 5°C). Current drain of heating element exhausts LBA
capacitors very fast
nected in-line with the battery positive terminal to the controller and
value and type depends on number of connected devices and wire length.
ng during
Binary output protections
Power supply fusing
A one-amp fuse should be con
modules.
Fuse
Recommended fuse (not fast) type - T1A. Not fast due to internal capacitors chargi
power up.
NOTE:
Do not connect binary outputs directly to DC relays without protection diodes, even if they are not
connected directly to controller outputs.
Grounding
To ensure proper function:
• Use as short as possible cable to the grounding point on the switchboard
• Use cable min. 2,5mm
2
• The “-“ terminal of the battery has to be properly grounded
