ComAp InteliLite MRS16 User Manual

7 Technical data
Power supply range
8-36 VDC
Power consumption
394 mA / 8 VDC
255 mA / 12 VDC
140 mA / 24 VDC
97 mA / 36 VDC
RTC battery
Replaceable
Fusing
2 A (without BOUT
consumption nor
extension modules)
Max. Power Dissipation
3,5W
Power supply
Operating
temperature
-20 ˚C to +70 ˚ C
Operating
temperature for LT
version
-40 ˚C to +70 ˚ C
Storage temperature
-30 ˚C to +70 ˚ C
Operating humidity
95 % w/o condensation
Vibration
5-25 Hz, ± 1,6 mm
25-100 Hz, a = 4 g
Shocks
a = 500 m/s
2
Surrounding air temperature rating 70°C.
Suitable for pollution degree 3.
Operating conditions
Measurement inputs
3ph-n Gen voltage
Measurement range
277 V
Max. allowed voltage
350 V
Accuracy
1 %
Frequency range
40-70 Hz (accuracy 0.1 Hz)
Input impedance
0,72 MΩ ph-ph
0,36 MΩ ph-n
Voltage measurement
Measurement
inputs
3ph Gen current
Measurement
range
5 A
Max. allowed
current
10 A
Accuracy
1,5 % for full temperature range (1 %
from 0 ˚C to 50 ˚C)
Input impedance
< 0,1 Ω
Current measurement
Number
7, non-isolated
Close/Open indication
0-2 VDC close contact
>6 VDC open contact
Binary inputs
Number
2 high current output, non-isolated
5 low current output, non-isolated
Max.
current
10 A for 10 s, 4 A long term
0,5 A
Switching
to
positive supply terminal
Binary outputs
Number
4 non-isolated
Type
Resistive
Resolution
0,1 Ω
Range
0-2500 Ω
Input impedance
800 Ω
Accuracy
±2 % from range in range
0-2500 Ω
±1,5 kΩ in range 2,5-15 kΩ
Analog inputs
Voltage input range
4 Vpk-pk to 50 Vpk-pk in
range 4 Hz to 1 kHz
6 Vpk-pk to 50 Vpk-pk in
range 1 kHz to 5 kHz
10 Vpk-pk to 50 Vpk-pk in
range 5 kHz to 10 kHz
Frequency input
range
4 Hz to 10 kHz
Frequency
measurement
tolerance
0,2 % from range 10 kHz
Magnetic pick-up
USB port
Non-isolated
CAN 1
CAN bus, 250 kbps, max 200 m, 120 Ω
termination option
non- isolated
Communications
InteliLite Global Guide
145

ComAp InteliLite MRS16 Specifications

General

Brand	ComAp
Model	InteliLite MRS16
Category	Controller
Language	English
