5 Controller setup
5.1 Default configuration 44
5.2 Controller configuration and PC tools connection 45
5.3 Operator Guide 52
5.4 Functions 73
6 back to Table of contents
5.1 Default configuration
5.1.1 Binary inputs
Number Description Configured function
BIN1 Remote start/stop command REMOTE START/STOP (PAGE 460)
BIN2 Access lock keyswitch ACCESS LOCK (PAGE 450)
BIN3 Emergency stop button EMERGENCY STOP (PAGE 453)
BIN4 Switch controller to OFF mode REMOTE OFF (PAGE 460)
BIN5 Suppression of alarms SD OVERRIDE (PAGE 461)
BIN6 Control lock keyswitch REMOTE CTRLLOCK (PAGE 459)
BIN7 Free slot NOT USED (PAGE 458)
5.1.2 Binary outputs
Number Description Function
BOUT1 Starter motor control STARTER (PAGE 510)
BOUT2 Fuel solenoid valve FUEL SOLENOID (PAGE 493)
BOUT3 Indication of breaker state GCB CLOSE/OPEN (PAGE 495)
BOUT4 Activation of any devices before start PRESTART (PAGE 506)
BOUT5 Gen-set can be connected to load READY TO LOAD (PAGE 508)
BOUT6 Indication of unconfirmed alarm ALARM (PAGE 476)
BOUT7 Free slot NOT USED (PAGE 505)
5.1.3 Analog inputs
Number Configured sensor Function
AIN1 VDO 10 Bar OIL PRESSURE (PAGE 546)
AIN2 VDO40-120°C COOLANT TEMP (PAGE 543)
AIN3 VDOLevel % FUEL LEVEL (PAGE 544)
AIN4 None NOT USED (PAGE 545)
To Next Page
