InteliLite Global Guide
18
4 Installation and wiring
4.1 Package content 18
4.2 Controller installation 19
4.3 Terminal Diagram 21
4.4 Recommended wiring 22
4.5 Plug-in module installation 41
4.6 Maintenance 42
6 back to Table of contents
4.1 Package content
The package contains:
Controller
Mounting holders
Terminal blocks
Note: The package does not contain a communication or extension modules. The required modules should be
ordered separately.
