InteliLite Global Guide
92
Image 5.21 Breaker fail - breaker close/open opens
When binary output breaker close/open closes there is 5 sec delay for breaker fail detection.
Image 5.22 Breaker fail - breaker close/open closes
5.4.11 Exercise timers
There are 2 exercise (general-purpose) timers in the controller. The timers are intended for scheduling of any
operations such as e.g. periodic tests of the gen-set, scheduled transfer of the load to the gen-set prior to an
expected disconnection of the mains etc.
Related setpoints for timer 1 are:
Timer 1 Function (page 264)
Timer 1 Repetition (page 265)
Timer 1 First Occur. Date (page 266)
Timer 1 First Occur. Time (page 266)
Timer 1 Duration (page 266)
Timer 1 Repeated (page 267)
Timer 1 Repeat Day (page 270)
Timer 1 Day (page 269)
Timer 1 Repeated Day In Week (page 270)
Timer 1 Repeat Day In Month (page 270)
Timer 1 Repeat Week In Month (page 271)
Timer 1 Refresh Period (page 268)
Timer 1 Weekends (page 269)
