InteliLite Global Guide
268
Setpoint group Scheduler Related FW 1.2.1
Range [units] [-]
Default value [-] Alternative config NO
Step [-]
Comm object 0 Related applications AMF, MRS
Config level Standard
Setpoint visibility
Conditioned by the setpoint Timer 1 Function (page 264)
Description
Refresh period of Timer 1 Function (page 264). Meaning of this setpoint depends on type of repetition
adjusted in Timer 1 Repeated (page 267).
Daily
Range [units]: 1 .. 1000 [day]. This setpoint adjust that every X day the timer will be
activated.
Example: If you have daily repetition and you set this setpoint to 2, then every
second day from first occurrence of Timer 1 Function (page 264), the Timer 1
Function (page 264) will be activated.
Weekly
Range [units]: 1 .. 60 [week]. This setpoint adjust that every X week the timer will be
activated.
Example: If you have weekly repetition and you set this setpoint to 2, then every
second week from first occurrence of Timer 1 Function (page 264), the Timer 1
Function (page 264) will be activated in selected days adjusted by Timer 1 Day
(page 269).
Monthly
Range [units]: 1 .. 12 [month]. This setpoint adjust that every X month the timer will be
activated.
Example: If you have monthly repetition and you set this setpoint to 2, then every
second month from first occurrence of Timer 1 Function (page 264), the Timer 1
Function (page 264) will be activated in selected day of month adjusted by Timer 1
Repeat Day In Month (page 270) or in selected days of week of month adjusted by
Timer 1 Day (page 269) and Timer 1 Repeat Week In Month (page 271).
Short Period
Range [units]: [HH:MM]. This setpoint adjust that every X short period the timer will
be activated.
Example: If you have short period repetition and you set this setpoint to 2, then
every second minute from first occurrence of Timer 1 Function (page 264), the
Timer 1 Function (page 264) will be activated.
Timer 1 Refresh Period
6 back to List of setpoints
