InteliLite Global Guide
404
8.1.2 Values
What values are:
Values (or quantities) are analog or binary data objects, measured or computed by the controller, that are
intended for reading from the controller screen, PC, MODBUS, etc. Values are organized into groups according
to their meaning.
Invalid flag
If valid data is not available for a particular value, the invalid flag is set to it. This situation may be due to the
following:
The value is not being evaluated in the scope of the current application and configuration.
Sensor fail has been detected on an analog input.
The configured ECU or extension module does not provide the particular value.
The communication with the ECU or extension module is interrupted.
A value containing the invalid flag is displayed as “####” in LiteEdit2015 and on the controller screen. If such a
value is read out via MODBUS, it will contain the data 32768 in the case of signed values and 65535 in the case
of unsigned values.
List of values groups
Group: Engine 407
Group: Generator 411
Group: Load 414
Group: Controler I/O 419
Group: Statistics 421
Group: IL Info 425
Group: Log Bout 427
Group: CM-GPRS 429
Group: CM-4G-GPS 434
Group: CM-Ethernet 440
Group: Date/Time 443
Group: Plug-In I/O 443
Group: PLC 444
For full list of setpoints go to the chapter List of values (page 405).
