InteliLite Global Guide
534
Related FW 1.2.1 Related applications AMF, MRS
Comm object 9981
Description
Logical analog input designed for general value received from analog sensor. For more information about
wiring of analog inputs see Analog inputs on page 33. Limits for this protection are adjusted by setpoints
Analog Protection 19 Wrn (page 256) and Analog Protection 19 Sd (page 257). Delay is adjusted by setpoint
Analog Protection 19 Delay (page 257).
Monitoring Analog value is only measured and displayed on the LCD screen but not used for
protection.
HistRecOnl Analog value is only measured and displayed on the LCD screen but not used for
protection. History record is made if value is out of the limits.
Wrn Analog value is used for warning protection only.
Wrn + BOC Analog value is used for warning and BOC (Breaker Open and Cooling) protection.
BOC Analog value is used for BOC (Breaker Open and Cooling) protection.
Wrn + Sd Analog value is used for warning and shutdown protection.
Sd Analog value is used for shutdown protection.
Protection types
Note: This parameter has to be adjusted via LiteEdit2015.
Under limit Alarm is activated when value of analog input is under adjusted limits
Over limit Alarm is activated when value of analog input is over adjusted limits
Under limit + fls Alarm is activated when value of analog input is under adjusted limits. If sensor fail
is detected then the alarm with higher level is activate as well.
Over limit + fls Alarm is activated when value of analog input is over adjusted limits. If sensor fail
is detected then the alarm with higher level is activate as well.
Alarm
Example: Protection type is Wrn + Sd. When sensor fail is detected then Sd alarm will be activated +
Sensor fail alarm will be activated.
Note: This parameter has to be adjusted via LiteEdit2015.
AIN Prot 19
6 back to Logical analog inputs alphabetically
