Image 9.33 Inteli IO8/8
Image 9.34 Inteli IO8/8 dimensions
Note: All dimensions are in mm.
Inputs and outputs
Binary inputs
8 channels
can be configured as:
pull up
pull down
All 8 inputs are configured to one type together.
All inputs can be configured to any logical function or protection.
