InteliPro, SW version 1.0, ©ComAp – May 2011
InteliPro Installation and Operation Guide
1-10
WIRING OF ANALOG INPUTS - USED AS BINARY OR TRISTATE
NOTE:
The name, sensor characteristic and alarm types for each analog input have to be assigned during the
configuration.
Recommended wiring
In the diagram below, see the typical wiring of the InteliPro unit inputs and outputs. The wiring is to be
considered as an example for the default configuration and operation mode with 1 common trip output
.
The relay contacts of Relay Card CT2-REL2 module can be reconfigured to Trip 1 and Trip 2 outputs
in case of operation with 2 trip outputs
, as well as any inputs and outputs can be reconfigured to the
particular needs of the application.
