ComAp InteliPro Comprehensive Guide

InteliPro, SW version 1.0, ©ComAp – May 2011
InteliPro Reference Guide
4-37
Baud rate 250kbps
Bus length max. 200m
Termination resistor 120Ohm, built-in, jumper activated
Interface to other controllers
Type CAN bus, available in MINT type only
Galvanic insulation Insulated, 500V
Baud rate 250kbps
Bus length max. 200m
Termination resistor 120Ohm, built-in, jumper activated
Relay Card CT2-REL2
The module is delivered as a default part of the InteliPro unit.
Relay contacts
Number of relay outputs 2
Type Dry contacts
Operating voltage 250 VAC
Max switched voltage/current 250 V / 10A
Current measurement inputs
2 x 1ph current measurement
Measurement type True RMS
Number of current inputs 2
Input 1 (CT k1, l1):
Current range 50 mA
Max. measured current 90 mA
Max. allowed current 120 mA
Current accuracy 2% from the range
Input 2 (CT k2, l2):
Current range 5 A
Max. measured current 9 A
Max. allowed current 12A continous, 50A/1s
Current accuracy 2% from the range
CT input burden <0.5VA
Recommended CAN cables
• Belden 3082A DeviceBus for Allen-Bradley DeviceNet
• Belden 3083A DeviceBus for Allen-Bradley DeviceNet
• Belden 3084A DeviceBus for Allen-Bradley DeviceNet
• Belden 3085A DeviceBus for Allen-Bradley DeviceNet
• Belden 3086A DeviceBus for Honneywell SDS
• Belden 3087A DeviceBus for Honneywell SDS
• Lapp Cable Unitronic Bus DeviceNet Trunk Cable
• Lapp Cable Unitronic Bus DeviceNet Drop Cable
• Lapp Cable Unitronic Bus CAN
• Lapp Cable Unitronic-FD Bus P CAN UL/CSA
